Knuckleboom

2026 HydraLift HLC F10.56

Brand New USA Designed Crane!
$52,850

CranesList ID: 1040

All Information Provided By The Seller

Crane Specifications

Overview


Year: 2026
Make: HydraLift
Model: HLC F10.56
Crane Type: Knuckleboom
Serial:
Tons: 10
Weight:
Location: Bulgaria
Price: $52,850
CranesList ID: 1040
Great Condition
Low Hours

Notes

  • ​​​​​​​​​​​​​​​UN-MOUNTED KNUCKEBOOM AND BOOM TRUCK CRANE ALL IN ONE...
  • 43' Maximum working horizontal extension,
  • 56' Maximum working height,
  • Hexagonal telescopic boom,
  • Independent hydraulic cylinders for the extension of the telescopic booms equipped with sequence valves,
  • with sequence valves,
  • No Jib,
  • 2.5 Ton Hydraulic winch capacity with one rope,
  • Visual and audio load indication (light bar indicating 80%, 90%, 100% and overload),
  • Electronic overload limiting device with stability control,
  • Slew angle : 380 deg (optionally can be endless),
  • Slew mechanism : gear – rack (optionally slew gear with slew drive)
  • Load holding valves in every function,
  • Full proportional wireless remote control,
  • Construction material 100% high strength steel Strenx 700 by SSAB,
  • Full hydraulic operated stabilizers in horizontal and vertical movement, Stabilizers spread 19 ft,
  • Maximum lifting moment : 110.000 ft lbs,
  • Maximum lifting weight : 10 US tn @ 5 ft,
  • Crane dead weight 5800 lbs,
  • Oil tank capacity 16. US gallons (optionally 30 gallons with separate oil talk to be fitted on the truck chassis),
  • Maximum working pressure : 295 bar,
  • Preferable oil flow : 60 L/m (16 gal/min),
  • Advantages Of This Crane: Unique design that only we are providing now.The crane is fully foldable exactly as a knuckle boom crane. The crane can work as a normal telescopic crane by using the hydraulic winch but also as a knuckle boom crane in horizontal position using the winch or a hook because of the design of the hexagonal telescopic booms and the independent hydraulic cylinders of them. Light dead weight. It is possible to be equipped with fly jib and this option makes it a powerful multipurpose lifting machine with abilities than none of the competitors can provide. Flexibility because of each unique design.

Location

Bulgaria

Crane Details

Boom/Jib

Boom/Jib Images
Boom:
Boom: ​​​​​43' Maximum working horizontal extension
Boom Length: 43'
Jib:
Jib: No Jib
Jib Length:
Boom/Jib Notes:
  • ​​​​​​​​​​​​​​​UN-MOUNTED KNUCKEBOOM AND BOOM TRUCK CRANE ALL IN ONE...
  • 43' Maximum working horizontal extension,
  • 56' Maximum working height,
  • Hexagonal telescopic boom,
  • Independent hydraulic cylinders for the extension of the telescopic booms equipped with sequence valves,
  • with sequence valves,
  • No Jib.

Carrier

Carrier images
Carrier: Un-Mounted Knuckeboom and Boom Truck Crane all in One
Mileage: Brand New Crane
Carrier Notes:
  • Un-Mounted Knuckeboom and Boom Truck Crane all in One.

Lifting System

Lifting System Images
Hours: Brand New Crane
Winches: Main Winch
Lifting System Notes:
  • 2.5 Ton Hydraulic winch capacity with one rope,
  • Visual and audio load indication (light bar indicating 80%, 90%, 100% and overload),
  • Electronic overload limiting device with stability control,
  • Slew angle : 380 deg (optionally can be endless),
  • Slew mechanism : gear – rack (optionally slew gear with slew drive)
  • Load holding valves in every function.

Hook Block/Hook Ball

Hook Block/Hook Ball Images
Hook Block/Hook Ball:
Hook Block/Hook Ball Notes:

Downloadable Files Associated with this Crane

Documents

Documents
f-10-56-load-chart.pdf (1.48 MB)

Click To Enlarge or Browse

All Images

Click To Enlarge or Browse

, , , , ,
