CranesList Comprehensive Crane Listing

All Terrain

1996 Demag AC435

Ready to Go to Work!
$377,750

CranesList ID: 1052

All Information Provided By The Seller

Crane Specifications

Overview


Year: 1996
Make: Demag
Model: AC435
Crane Type: All Terrain
Serial: 37229
Tons: 180
Weight: 241,150# Complete Crane (incl. block, ball & max. cwt.)
Location: Texas
Price: $377,750
CranesList ID: 1052
Good Condition

Notes

  • 42' to 164' consisting of 1 base section and 4 telescopic sections Full Power Boom,
  • No Jib,
  • Mercedes OM 366, 6-Cylinder, 163 hp, Water Cooled Diesel Engine Upper - SUBJECT TO FINAL CONFIRMATION,
  • Main and Auxiliary Winches with 21mm wire rope,
  • Two Speed, Electronic safe load indicator with digital readout for hook load, rated load, boom length, boom angle, load radius, analog display to indicate the capacity utilization, limit switches on hoist and lowering motions, pressure-relief and safety holding valves,
  • 44,000# Self-Removable Counterweights,
  • Hook Block,
  • Demag 10 x 8 x 8 drive/steering Carrier,
  • Mercedes OM442LA water cooled 8-Cylinder Diesel Engine - SUBJECT TO FINAL CONFIRMATION,
  • ZF Transmatik, 16 speeds forward, 2 reverse lncluding. off-road Range Transmission - SUBJECT TO FINAL CONFIRMATION,
  • Front and Rear Tires: 16.00 R 25 - SUBJECT TO FINAL CONFIRMATION,
  • Four hydraulically telescoping outrigger beams with hydraulic jack legs.

Location

Texas

Crane Details

Boom/Jib

Boom/Jib Images
Boom:
Boom: 42' to 164' consisting of 1 base section and 4 telescopic sections Full Power Boom
Boom Length: 164'
Jib:
Jib: No Jib
Jib Length:
Boom/Jib Notes:
  • 42' to 164' consisting of 1 base section and 4 telescopic sections Full Power Boom,
  • No Jib.

Carrier

Carrier images
Carrier: Demag 10 x 8 x 8 drive/steering Carrier
Mileage:
Carrier Notes:
  • Demag 10 x 8 x 8 drive/steering Carrier,
  • Mercedes OM442LA water cooled 8-Cylinder Diesel Engine - SUBJECT TO FINAL CONFIRMATION,
  • ZF Transmatik, 16 speeds forward, 2 reverse lncluding. off-road Range Transmission - SUBJECT TO FINAL CONFIRMATION,
  • Front and Rear Tires: 16.00 R 25 - SUBJECT TO FINAL CONFIRMATION.

Lifting System

Lifting System Images
Hours: 62,730 lower and 10,859 upper as of 2.2026
Winches: Main Winch, Auxiliary Winch
Lifting System Notes:
  • Main and Auxiliary Winches with 21mm wire rope,
  • Two Speed, Electronic safe load indicator with digital readout for hook load, rated load, boom length, boom angle, load radius, analog display to indicate the capacity utilization, limit switches on hoist and lowering motions, pressure-relief and safety holding valves.

Hook Block/Hook Ball

Hook Block/Hook Ball Images
Hook Block/Hook Ball: Hook Block
Hook Block/Hook Ball Notes:
  • Hook Block.
